Refer to the exhibit.

In the WTP profile configuration shown in the exhibit, the AP profile is assigned to two FAP-320 APs that are installed in an open plan office.

1.

The first AP has 32 clients associated to the 5GHz radios and 22 clients associated to the 2.4GHz

radio.

2.

The second AP has 12 clients associated to the 5GHz radios and 20 clients associated to the 2.4GHz radio.

A dual band-capable client enters the office near the first AP and the first AP measures the new client at −33 dBm signal strength. The second AP measures the new client at −43 dBm signal strength.

In the new client attempts to connect to the corporate wireless network, to which AP radio will the client be associated?

A. The second AP 5GHz interface.

B. The first AP 2.4GHz interface.

C. The first AP 5GHz interface.

D. The second AP 2.4GHz interface.

An administrator is deploying APs that are connecting over an IPsec network. All APs have been configured to connect to FortiGate manually. FortiGate can discover the APs and authorize them. However, FortiGate is unable to establish CAPWAP tunnels to manage the APs.

Which configuration setting can the administrator perform to resolve the problem?

A. Decrease the CAPWAP tunnel MTU size for APs to prevent fragmentation.

B. Enable CAPWAP administrative access on the IPsec interface.

C. Upgrade the FortiAP firmware image to ensure compatibility with the FortiOS version.

D. Assign a custom AP profile for the remote APs with the set mpls-connectionoption enabled.

Refer to the exhibit.

A host machine connected to port2 on FortiSwitch cannot connect to the network. All ports on FortiSwitch are assigned a security policy to enforce 802.1X port authentication. While troubleshooting the issue, the administrator runs the debug command and obtains the output shown in the exhibit.

Which two scenarios are the likely cause of this issue? (Choose two.)

A. The host machine is not configured for 802.1X port authentication.

B. The host machine does not support 802. 1X authentication.

C. The host machine is quarantined due to a security incident.

D. The host machine is configured with wrong VLAN ID.

What action does FortiSwitch take when it receives a loop guard data packet (LGDP) that was sent by itself?

A. The receiving port is shut down.

B. The sending port is shut down

C. The receiving port is moved to the STP blocking state.

D. The sending port is moved to the STP blocking state

Default VLANs are created on FortiGate when the FortiLink interface is created. By default, which VLAN is set as Allowed VLANs on all FortiSwitch ports?

A. Sniffer VLAN

B. Camera VLAN

C. Quarantine VLAN

D. Voice VLAN

What does DHCP snooping MAC verification do?

A. Drops DHCP release packets on untrusted ports

B. Drops DHCP packets with no relay agent information (option 82) on untrusted ports

C. Drops DHCP offer packets on untrusted ports

D. Drops DHCP packets on untrusted ports when the client hardware address does not match the source MAC address

Refer to the exhibits.

Examine the firewall policy configuration and SSID settings.

An administrator has configured a guest wireless network on FortiGate using the external captive portal. The administrator has verified that the external captive portal URL is correct. However, wireless users are not able to see the captive portal login page.

Given the configuration shown in the exhibit and the SSID settings, which configuration change should the administrator make to fix the problem?

A. Enable the captive-portal-exemptoption in the firewall policy with the ID 11.

B. Apply a guest.portal user group in the firewall policy with the ID 11.

C. Disable the user group from the SSID configuration.

D. Include the wireless client subnet range in the Exempt Source section.

Refer to the exhibit.

The exhibit shows a network topology and SSID settings.

FortiGate is configured to use an external captive portal. However, wireless users are not able to see the captive portal login page.

Which configuration change should the administrator make to fix the problem?

A. Create a firewall policy to allow traffic from the Guest SSID to FortiAuthenticator and Windows AD devices.

B. Enable the captive-portal-exemptoption in the firewall policy with the ID 10.

C. Remove guest.portal user group in the firewall policy.

D. FortiAuthenticator and WindowsAD address objects should be added as exempt sources.

Examine the following output from the FortiLink real-time debug.

Based on the output, what is the status of the communication between FortiGate and FortiSwitch?

A. FortiGate is unable to authorize the FortiSwitch.

B. FortiGate is unable to establish FortiLink tunnel to manage the FortiSwitch.

C. FortiGate is unable to located a previously managed FortiSwitch.

D. The FortiLink heartbeat is up.

An administrator has deployed dual band-capable wireless APs in a wireless network. Multiple 2.4 GHz wireless clients are connecting to the network, and subsequent monitoring shows that individual AP

2.4GHz interfaces are being overloaded with wireless connections. Which configuration change would best resolve the overloading issue?

A. Configure load balancing AP handoff on both the AP interfaces on all APs.

B. Configure load balancing AP handoff on only the 2.4GHz interfaces of all Aps.

C. Configure load balancing frequency handoff on both the AP interfaces.

D. Configure a client limit on the all AP 2.4GHz interfaces.
