You need to configure iSCSI on your existing ONTAP cluster in a new SVM. The iSCSI LUNs will be served over a new Layer 2 network using the same physical ports that also use the CIFS protocol on a different SVM.

Which two actions should you perform to accomplish this task? (Choose two.)

A. Create a new portset.

B. Create a new VLAN.

C. Create a new broadcast domain.

D. Create a new AD object.

After the addition of extra DS224C disk shelves, you notice that the output of the system node run -node node_1 sysconfig command shows Mixed-path. You need to investigate why the additional shelves are providing this error. In this scenario, which two tools would help diagnose this issue? (Choose two.)

A. Config Advisor

B. Active IQ

C. Hardware Universe (HWU)

D. Interoperability Matrix Tool (IMT)

Which type of multipathing does Linux support?

A. dm_mp

B. dsm

C. mpio

D. mcs

You want to provision an iSCSl LUN.

Which two steps are required to accomplish this task? (Choose two.)

A. Add the initiator IP address to the igroup.

B. Map the LUN to the igroup.

C. Add the target WWPN to the igroup.

D. Add the initiator 1QN to th

Which configuration for primary block (FC and iSCSI) data does NetApp best practices recommend? (Choose two.)

A. single controller single shelf

B. single controller multiple shelves

C. dual controller single shelf

D. dual controller multiple shelves

You need to move a LUN non-disruptively from an AFF A200 HA pair to an AFF A700 HA pair within the same 4-node cluster using the steps shown below.

1.

Scan the host OS to discover all paths to the LUN.

2.

Execute the lun move command to move the LUN to the AFF A/00 HA pair.

3.

Remove the AFF A200 HA pair from the reporting-nodes list.

4.

Add the AFF A700 HA pair to the reporting-nodes list. What is the correct sequence in performing, these steps?

A. 1, 2, 3. 4

B. 4. 1, 2, 3

C. 4, 3. 2. 1

D. 3, 2, 1,4

Which four FC fabric topologies does NetApp support? (Choose four.)

A. four FC switches with multiple Inter-Switch Links (ISLs) between each pair of switches

B. ten FC switches per fabric, daisy chained with a single ISL between switches

C. four FC switches with multiple ISLs between ALL switches

D. eight FC switches with no more than a single ISL between switches in a cascade topology

E. dual FC switches with no ISLs

F. a single FC switch

G. a switched fabric that has 65537 ports

You are configuring a VMware sphere host for FC access to a Netapp ONTAP cluster. In this scenario, which two tasks does Netapp recommend performing on the Vsphere host? (choose two)

A. Set the queue depth on the host to 8

B. Update the HBA driver

C. Zone the host by using the host WWNNs

D. Use the Netapp Virtual Storage Console to configure the host settings

You created a LUN in a new volume on your Netapp ONTAP cluster. You enabled the default snapshot schedule and enabled snapshot autodelete on the volume. In this scenario, in which three situations does the snapshot autodelete feature automatically delete snapshot copies in the volume? (choose three)

A. The snapshot reserve space is nearly full

B. The LUN is nearly full

C. The overwrite reserve space is full

D. The volume is nearly full

E. The aggregate is nearly full

An administrator enabled the FCP protocol on an SVM and created a boot LUN for a Windows Server 2019 server host. The host is attached using multiple paths to the storage SVM. After correctly adding the LUN to the igroup and setting its LUN ID to 1, the host is unable to boot using the installed FC HBA.

A. The LUN ID must be set to 0

B. The LUN ID must be set to 255

C. During the boot process, using FCP is not supported by Netapp D. During the boot process, using FCP is not supported by Microsoft
