Click the Exhibit button.

Referring to the exhibit, which statement about the IS-IS interface is true?

A. The ge-0/0/0.0 interface will act as an L1/L2 interface

B. The ge-0/0/0.0 interface will act as an L2 interface only

C. The ge-0/0/0.0 interface will act as an L1 interface only

D. The ge-0/0/0.0 interface will not be assigned to a level

Which two statements are true for GRE tunneling? (Choose two.)

A. GRE tunnel endpoints must have a valid route to the remote endpoint

B. GRE tunnels support multiple logical units per interface

C. GRE tunnels are stateful by default

D. GRE tunnels support only one logical unit per interface

Which two statements are correct about the BGP MED attribute? (Choose two.)

A. BGP uses the MED value when peering to two or more connections to the same upstream AS

B. BGP routes require the MED attribute be defined

C. BGP uses the MED value when peering to two different upstream ASs

D. BGP assumes the MED value to be 0, if not already defined

Click the Exhibit button.

You have configured IPv6 over IPv4 tunneling, as shown in the exhibit. However, hosts connected to network 2001:0:0:1::0/64 cannot communicate with hosts on network 2001:0:0:2::0/64. The router R2 has a similar configuration as the R1 router.

How would you solve this problem?

A. Configure an IGP across the tunnel interfaces

B. Configure an IPv6 address on the tunnel interfaces

C. Configure the next hop of the inet6.0 static route to point to the physical interface between the routers

D. Configure the next hop of the inet6.0 static route to point to the IPv4 address of the remote router

Click the Exhibit button.

Both configuration hierarchies shown in the exhibit have been committed to your MX Series device.

Which two statements are true in this scenario? (Choose two.)

A. Traffic destined to 10.3.0.1 will use the R1-to-R6 LSP as a next hop

B. Traffic destined to 10.3.0.1 will not use the R1-to-R6 LSP as a next hop

C. The active 10.3.0.0/24 prefix installed in the route table will have a route preference of 5

D. The active 10.3.0.0/24 prefix installed in the route table will have a route preference of 7

You are asked to change the default TTL handling behavior on your Junos device to ensure that the RSVP-signaled LSPs in your MPLS network cannot be mapped.

Which configuration should be performed to accomplish this task?

A. Configure the no-decrement-ttl parameter for each LSP on the ingress device

B. Configure the no-propagate-ttl parameter for each LSP on the egress device

C. Configure the no-propagate-ttl parameter for each LSP on the ingress device

D. Configure the no-decrement-ttl parameter for each LSP on the egress device

Which two IP addresses are considered Martian addresses? (Choose two.)

A. 0.0.0.0/8

B. 192.168.0.0/8

C. 240.0.0.0/4

D. 169.254.0.0/16

Click the Exhibit button.

Referring to the exhibit, which two statements are true? (Choose two.)

A. The OSPF neighbor will be declared down if BFD hello packets are not received for 1.5 seconds

B. The OSPF neighbor will be declared down if BFD hello packets are not received for 5 seconds

C. The OSPF neighbor will be declared down if 500 BFD hello packets are missed

D. The OSPF neighbor will be declared down if three BFD hello packets are missed

Which MPLS feature works with Constrained Shortest Path First (CSPF) to protect against the primary and secondary paths using the same link?

A. fate-sharing

B. explicit null configuration

C. policy control over LSP selection

D. LSP metrics

When working with an MPLS LSP, what will the install 172.16.6.0/24 active command accomplish?

A. The command will swap the prefix from inet.0 to inet.3

B. The command will swap the prefix from inet.3 to inet.0

C. The command will install the prefix in inet.0 rather than inet.3

D. The command will install the prefix in inet.3 rather than inet.0
