A network engineer is having a problem adding a custom-written script to an AOS-CX switch's NAE GUI. The script was written in Python and was successfully added on other AOS-CX switches. The engineer examines the following items from the CLI of the switch:

What should the engineer perform to fix this issue?

A. Install the script's signature before installing the new script

B. Ensure the engineer's desktop and the AOS-CX switch are synchronized to the same NTP server

C. Enable trust settings for the AOS-CX switch's SSL certificate

D. Remove a script that is no longer used before installing the new script

Examine the commands entered on an AOS-CX switch:

What is true regarding this configuration for traffic received on interface 100?

A. The default next-hop address supersedes the two preceding next-hop addresses

B. The traffic is always dropped is the next-hop addresses are unreachable

C. The traffic will be routed with the IP routing table entries if the next-hop addresses are unreachable

D. The next-hop address of 1.1.1.1 is overwritten by the next-hop address of 2.2.2.2

In AOS-CX switching, what determines when a frame is forwarded by the switch between the ingress and the egress port?

A. Egress port

B. Ingress port

C. VSX switch tables

D. Fabric Load Balancer

Examine the attached diagram.

The two PCs are located in VLAN 11 (10.1.11.0/24). Which example defines how to implement active gateway on the VSX core for VLAN 11?

A. interface vlan 11 active-gateway ip 10.1.11.1 active-gateway mac 02:02:00:00:01:00

B. interface lag 254 active-gateway vlan 11 ip 10.1.11.1 active-gateway vlan 11 mac 02:02:00:00:01:00

C. interface lag 254 active-gateway ip 10.1.11.1 active-gateway mac 02:02:00:00:01:00

D. vsx vrrp group 1

An administrator is managing a pair of core AOS-CX switches configured for VSX. Connected to this core are pairs of aggregation layer AOS-CX switches configured for VSX. OSPF is running between the aggregation and core layers. To speed up OSPF convergence, the administrator has configured BFD between the core and aggregation switches.

What is a best practice the administrator should implement to reduce CPU processing on the switches if a BFD neighbor fails?

A. Disable ICMP redirects

B. Implement graceful restart

C. Increase the BFD echo timers

D. Increase the VSX keepalive timer

An administrator is designing an access layer solution in a data center. A key requirement is to dual-home mission-critical server connections to two different switches, ensuring that the servers always have network access, even during switch software upgrades. This feature should support strictly-controlled provisioning.

What would best meet the administrator's needs when deploying AOS-CX switches?

A. VSF

B. Dynamic segmentation

C. VSX

D. NAE

Examine the network topology.

Company XYZ has two connections to a service provider (ISP1). Here is the configuration of Router1:

Here is the configuration of Router2:

Based on configuration of Router1 and Router2, which BGP metric is being manipulated?

A. Weight

B. Multiple exit discriminator

C. Local preference

D. AS path length

The network is configured for OSPF with the following attributes: Core1 and Core2 and ABRs Area 1 has 20 networks in the 10.1.0.0/16 range Area 0 has 10 networks in the 10.0.0.0/16 range Area 2 has 50 networks in the 10.2.0.0/16 range The ASBR is importing a static route into Area 1 Core2 has a summary for Area 2: area 0.0.0.2 range 10.2.0.0/16 type inter-area Here is the OSPF configuration performed on Core1: Based on the above information, what is correct?

A. Area 0 has 13 routes

B. Core1 has no OSPF routes

C. Core1 has received one LSA Type 5 from the ASBR

D. Area 1 has 23 routes

An administrator is looking for a data center switching solution that will greatly reduce the likelihood of dropped frames when uplink congestion is experienced. Which AOS-CX switch queuing feature meets the administrator's needs?

A. FIFO

B. VOQ

C. WFQ

D. DWWR

Examine the network exhibit.

A company has a guest implementation for wireless and wired access. Wireless access is implemented through a third-party vendor. The company is concerned about wired guest traffic traversing the same network as the employee traffic. The network administrator has established a GRE tunnel between AOS-CX switches where guests are connected to a routing switch in the DMZ.

Which feature should the administrator implement to ensure that the guest traffic is tunneled to the DMZ while the employee traffic is forwarded using OSPF?

A. OSPF route maps using the "set metric" command

B. Policy-based routing (PBR)

C. User-based tunneling (UBT)

D. Classifier policies
