DRAG DROP

Match each HPE server platform with optimal workload.

Select and Place:

HOTSPOT

An integrator has added a new CPG using SSMC, but the CPG is not visible in the HPE Composer. The storage system is online and healthy.

Click on the option that will make the new CPG visible in the HPE Composer.

Hot Area:

HOTSPOT

An integrator needs to configure zoned SAS drives from the HPE Synergy D3940 storage module for an HPE SY 480 Gen9 compute module for a new application.

Click where the integrator should perform the configuration.

Hot Area:

A customer has a datacenter with 3-frame Master/Satellite Synergy solution. They plan to add two additional frames to the remote datacenter, but they want to have a single management tool. How should the integrator set up the management of the datacenter?

A. Add two frames from the remote datacenter as remote enclosures using existing Composer

B. Install one Composer in every frame in both local and remote datacenter

C. Deploy one Composer in each site and link them together

D. Connect the management links with fibre cables if the distance between datacenters is more than 500m

An integrator needs to configure a set of networks for Synergy compute nodes to send data to devices outside of a Synergy frame. How should the integrator complete the task?

A. Add the network to an interconnect bay within a Logical Enclosure (LE)

B. Add the networks to an uplink set within a Logical Interconnect Group (LIG)

C. Add the networks to an Enclosure Group (EG)

D. Add the network sets to a Logical Interconnect Group (LIG)

Which HPE Synergy D3940 storage module configuration is valid?

A. a single RAID set to be shared across the SAS fabric to multiple compute nodes as a virtualization host datastore

B. maximum of three HPE Synergy D3940 storage modules per frame to be used by any compute module within the management ring

C. any number of the drives from storage module to be mapped to any single compute node

D. a pair of disks to house Composer backups and Synergy firmware bundles

A customer is considering implementing a DRS cluster, but they would like to know how DRS can help to achieve performance goals.

How should an integrator respond?

A. When powering on a virtual machine, a DRS cluster can automatically place it on the optimal host.

B. Selected virtual machines will be assigned higher priority when the amount of physical resources will drop below a specific level.

C. A DRS cluster will migrate a virtual machine to a different host when available network bandwidth will drop below a specific level.

D. If more than 50 virtual machines will be running on a single host, DRS cluster will configure CPU affinity to proportional resource allocation.

A customer needs to attach 20 HPE 1 TB SATA 6G SFF hard drives to an HPE Synergy 480 Gen10 compute module. Which HPE products are necessary to meet the requirements? (Choose three.)

A. HPE D3940 storage module

B. HPE Synergy 12Gb SAS Connection Module

C. HPE 10GbE SynergyPass-Thru Module

D. HPE Smart Array P416ie-m Controller

E. HPE Smart Array P542D Controller

An integrator needs to enable automatic support case logging for hardware incidents as part of a new Synergy installation. Which configuration steps should the integrator perform to enable support case creation for the frame and all compute nodes?

A. Enable Remote Support in HPE Composer, and register with HPE

B. Enable Insight Online integration in the composer

C. Install Insight Online, and register with HPE Passport credentials

D. Install Insight Remote Support Advanced (RSA)

A customer's Synergy configuration requires HPE Synergy 12Gb SAS Connection Modules in interconnect module bays 1 and 4, and HPE Virtual Connect SE 40Gb F8 modules for HPE Synergy ICMs in interconnect module bays 2 and 5. What must the integrator verify in the HPE Synergy 480 Gen10 Compute Module configuration to validate this solution configuration? (Choose two.)

A. SAS controllers have HPE Compute Module Smart Array P542D SAS Cables

B. Both processor slots are populated

C. HPE Synergy 2820C 10Gb Converged Network Adapter is in Mezzanine 2

D. A minimum of 128Gb of RAM is on each server

E. HPE Smart Array P542D/2GB FBWC 12Gb Mezzanine SAS Controller is in Mezzanine 3
