A customer asks you to architect a new SAN fabric infrastructure comprised of redundant fabrics for a test/dev server environment. They need to provide selective connectivity for array-based snapshots from disk arrays hosted on the existing Cisco MDS 9506 Multilayer director-based production fabric, to hosts on the test/ dev fabric. A customer requirement is to utilize a different vendor for the test/dev fabric. Which SAN technology enables the test/dev SAN fabric to maintain interoperability between the two fabrics and meet the stated requirements?
A. HP B-Series with Transparent Router (TR)
B. HP H-Series with Transparent Router (TR)
C. HP B Series with Inter-VSAN Routing (iVR)
D. HP H-Series with Inter-Fabric Routing (IFR)
Your customer wants to upgrade their existing HP 3PAR S-Class array. A competitor has suggested a non-HP storage array. Your conversation with the customer focuses on the notable architectural enhancements within the new generation of HP 3PAR StoreServ 7400 platforms.
Which enhancements should you focus on? (Select two.)
A. The tightly coupled cache-coherent clustering is built into the Gen4 ASIC.
B. The 64-bit OS enables scalable headroom for performance and capacity.
C. Logical Disk regions have increased from 256 MB and are now 1 GB in size.
D. Write cache mirroring is now implemented N+N across the 7x00 controllers.
E. New HP StoreServ 7x00 now supports 16Gb Fibre Channel speeds.
While discussing a remote replication solution consisting of two HP 3PAR StoreServ arrays, the customer asks you about performance penalties when implementing synchronous replication to a second HP 3PAR StoreServ array. How should you respond?
A. Synchronous replication affects write performance on the source array.
B. Synchronous replication affects both read and write performance on the source array.
C. Synchronous replication affects read performance on the source array.
D. Synchronous remote replication does not affect performance on the source array.
A client wants to deploy a new HP 3PAR 7400 storage environment. They want to utilize additional features of the array to optimize their backup and data restore capabilities. Which HP 3PAR software suite should you recommend?
A. Replication
B. Thin
C. System Tuner
D. Security
You are reviewing a colleague's extended fabric design, which proposes an HP 1606 Extension SAN Switch.
Which customer requirement should lead you to choose an HP Multi-protocol Router Blade for the B-Series as an alternative?
A. Requirement to extend the fabric between sites
B. Concerns around fabric stability
C. Requirement to support dark fiber metro connectivity
D. Need for up to 10 Gbs replication bandwidth
Refer to the scenario.
A large publicly-traded motion picture exhibitor that is a leader in digital and 3D cinema deployments operates 233 theaters and more than 2,200 screens in small to mid-sized communities in 35 states around the United States. They rely on
MS Exchange Server 2010 for email. MS SQL Server 2010 for analyzing data about movies and theater-goers, and MS Excel 2010 for crunching numbers.
The company runs nightly incremental backups and a full weekly backup that consists of close to 7 TB of data which takes up 72 hours to complete. The quarterly backups add an additional 7 TB of data. Tapes are inventoried and transported
from the main data center to the disaster recovery site 150 miles away. The process of transporting tape cartridges to and from the Disaster Recovery site requires hours of daily work.
The company currently relies on an aging robotic tape library and a process that takes the nightly backup tapes offsite every morning. Additionally, the company keeps an inventory, and if a restore is necessary they have to retrieve the tapes
from the DR site and transport them to the main data center site They have a 7 year data retention plan, and the tapes are expensive and not always reliable. Given the company's current system, if a full weekly backup fails over a weekend,
the re-run could take up to 10 hours, even if just one job failed.
The company has deployed a virtualized server infrastructure which runs VMware vSphere 5 on HP BladeSystem c7000 enclosures and BL460c servers interconnected with HP Virtual Connect Flex-10 10Gb Ethernet Modules as well as
several HP ProLiant DL380 servers. The company's top four IT improvements goals are as follows:
-replacing the aging robotic tape library
-enabling replication of backed up data from the main data center to the disaster recovery site (150 miles)
-retaining more backup data in smaller disk space
- increasing efficiency reliability, and ease of system administration Moreover the company's top three business benefit goals are as follows:
-increased confidence in disaster recovery
-minimal disruption by backups during regular business hours
-improved management of external audits
The company has asked that you create multiple solution proposals and prioritize one when you return for a presentation.
How does an HP StoreOnce Backup solution meet the customer IT and business needs?
A. Eliminates the need for tape backups for long-term archiving
B. Multiplies the data, which is then replicated to a remote location
C. Backs up the data via a WAN link
D. Provides a bandwidth-effective replication to remote sites
Refer to the scenario.
A university provides liberal arts training to 2,500 students in 68 classrooms and provides a growing suite of IT services that encompass dorm rooms and classrooms. All 2,500 students are provisioned an HP EliteBook Tablet PC to access
these services. Students use these tablet PCs for taking notes, handling documents, communicating with each other and with instructors, and participating in distance-education classes.
Additionally, by using their tablet PCs as thin clients, science and engineering students leverage virtual desktop infrastructure (VDI) and HP Remote Graphics Software to access applications that run on high-powered HP blade servers. All 68
classrooms are multi-media equipped, enabling instructors to record lectures for the college s closed circuit TV system. The university has implemented enterprise content management (ECM) applications, including Microsoft SharePoint for
document imaging and workflow for staff and faculty, as well as for external accrediting bodies.
Additionally, a recent initiative to implement voice-over-IP telephone communications on campus has started.
The compute environment is based on VMware vSphere using HP BL460c and BL680c G7 server blades in c7000 enclosures within two data centers.
The university needs to develop computing solutions to address the following problems and current initiatives:
-The current backup-to-tape environment creates downtime for backups of 6 to 12 hours.
- Each incoming class of 600 floods the registration system within the first hours after it opens. The server and network gridlock caused by this high workload prolongs the registration process by as much as one hour per student.
-Proof of concept is necessary for distance education involving large volumes of video and major bandwidth requirements.
- Top tier data must be replicated between two data centers over a 10 Gbps network Disaster recovery has a recovery time objective (RTO) of 120 minutes and network utilization should be minimized.
-Seven TB of first tier data needs to be migrated from the current fibre channel storage solution to nearline storage.
- Second tier data requires deployment of a separate storage solution. The university's top four IT improvements goals are as follows:
-Provide a robust replication capability between data centers.
-Reduce server downtime with faster backups.
-Retain more backup data in smaller disk space.
- Increase efficiency, reliability, and ease of system administration. Moreover the college's top three business benefit goals are as follows:
-Reduce student registration time.
-Increase number of servers while minimizing the need for additional staff to support them.
-Utilize IT resources and staff as efficiently as possible.
The company has asked that you create multiple solution proposals and prioritize one when you return for a presentation.
Which HP 3PAR Storage technology will allow the customer to automatically migrate data between different disk types to meet one of the stated business goals?
A. Autonomic Rebalance
B. Dynamic Optimization
C. Peer Motion
D. Adaptive Optimization
You are architecting an HP StoreOnce Backup System solution for a customer with a primary and a secondary data center on the same campus.
Backed up fileserver data should be replicated across data centers by VTL replication after a backup is completed.
Customer gives you these sizing requirements:
Backup of one fileserver with 6 partitions, 150GB each
Daily full backup
Daily change rate by less 1% of the original data
Backup application is Data Protector 7.01
Retention time of 120 days should be achieved
Uni-directional replication between sites
Which HP StoreOnce Backup System is most cost effective and meets customer requirements?
A. HP StoreOnce 2620 Backup System
B. HP StoreOnce 4210 Backup System
C. HP StoreOnce 4220 Backup System
D. HP StoreOnce 4420 Backup System
A leading automotive technology company wants to increase the performance and capacity of the storage infrastructure that supports the design and manufacture of its line of Formula 1 racing cars. The company is also interested in safeguarding its mission-critical data and eliminating the threat of business disruption. Due to the massive engineering and technical effort required to create a new race car design and to enable regular delivery of upgraded parts to the race track while maintaining a competitive edge, it is necessary to have advanced applications running on a high-performance IT infrastructure. The company operates out of two data centers. The centers support a Plant Lifecycle Management database, an Enterprise Resource Planning (ERP) system, and various trackside systems to set up the race car and aid race strategy. In addition, the centers run applications for Computer-Aided Design (CAD) Computer-Aided Manufacturing (CAM), and Computational Fluid Dynamics (CFD) packages. The company has deployed Oracle and SQL databases, VMware virtual machines, email, and all other applications on an HP 6400 Enterprise virtual Array (EVA). The EVAs automatically replicate between the two data centers to guard against failure. The EVAs are aging, applications are more sophisticated, data volumes have grown exponentially, and bottlenecks in the storage system are now having a significant effect on the performance of the simulation and analysis tools that are vital to the company's competitive position. The data storage problem has reached a point where the company is forced to store primary data at the secondary site causing the loss of their disaster recovery capability.
The company's top five IT Improvement goo's are:
-Reduce complaints about storage system availability.
-increase support for sophisticated design and manufacturing applications.
-Provide a robust replication capability between data centers.
-increase storage utilization while deploying additional capacity.
-Simplify operations during peak workloads.
Moreover, the company's top three business benefit goals are:
-Ensure rapid data retrieval to aid in quick decision making.
-Protect mission-critical data and ensure business continuity.
-Recover costs from existing infrastructure, thus providing increased IT funds for additional projects.
You are planning to use HP StoreOnce Backup Systems and HP StoreOnce Catalyst to replicate data to the primary data center after a Formula 1 race and then to the secondary data center.
Which information is relevant to size this solution component? (Select two.)
A. which type of application data is used at the Formula 1 race track
B. how many users will access the data during the weekend
C. how much data has changed during a race weekend
D. which online storage is used at the race track and data center
E. which hypervisor is used on the servers at the race track
You are working with a customer to design and install a Fibre Channel storage solution based on HP 3PAR StoreServ Storage.
The customer wants data migration to be part of the solution. The IT environment includes VMware vSphere 5 and Windows 2008 R2 servers.
The customer intends to utilize the existing non-HP array for Tier 2 storage on the Windows 2008 R2 servers.
The existing array is also being used as the target of the customer backups. and that data will not be migrated.
The customer wants to capitalize on their previous purchases and spend as little as possible for data migration. What should you recommend the customer use to migrate the data? (Select two)
A. HP 3PAR Remote Copy
B. HP MPX200 Multifunction Router
C. HP 3PAR Online Import
D. HP 1606 Extension SAN Switch
E. VMware Storage \/Motion
