Alcatel-Lucent Virtual Private Routed Networks: 4A0-106

In a traditional layer 3 VPN which of the following will be an issue when there is overlapping address space between two customers? Choose the best answer.

A. There will be increased memory usage on the PE

B. There will be increased CPU utilization on the PE

C. The CE will reject the overlapping prefix

D. The PE will not recognize the prefixes as being different

E. There is no issue with overlapping address space in a traditional Layer 3 VPN

Which command should be used on an Alcatel-Lucent 7750 SR acting as the PE, to view the table containing the BGP routes received from the remote sites?

A. Show router bgp routes

B. Show router bgp routes address-family vpn-ipv4

C. Show router bgp routes

D. Show router bgp routes

Which of the following statements about the control plane in Carrier Supporting Carrier (CSC) VPRN is FALSE?

A. The customer carrier does not learn any network provider routes.

B. The network provider must learn the customer carrier PE and CE system addresses.

C. Routes exchanged between CSC-CE and CSC-PE are labeled.

D. The customer carrier PE system addresses are populated in the CSC VRF.
