Refer to the exhibit.
Which two statements about the routing table of the leaf switch are true? (Choose two.)
A. The next hop 10.0.1.14 for route 172.16.99.0/24 is the TEP address of a border leaf in ACI.
B. 172.16.100.0/24 is a BD subnet in ACI.
C. The next hop 10.0.8.65 for route 10.20.1.0./24 is the TEP address of a border leaf in ACI.
D. The next hop 10.1.168.95 for route 172.16.100.0/24 is the TEP address of a border leaf in ACI.
E. 10.20.1.0./24 is a BD subnet in ACI.
What is a feature of NFS?
A. role-based access control
B. Kerberos-based security model
C. block-based file access
D. zone-based access control
An engineer configures the properties of a Cisco UCS Cisco Integrated Management Controller network adapter for a standalone Cisco C-Series Server. The Failback Timeout in the vNIC was set to 600. When the failure occurs, the secondary interfaces must be used and then failback when the primary interface becomes available again.
Which action must be taken to meet these requirements?
A. Set default VLAN on the adapters.
B. Increase CoS to 6.
C. Enable Uplink Failover.
D. Disable VNTAG mode.
An engineer must design an automation solution for the Cisco ACI Fabric to speed up the deployment of logical network elements for tenant provisioning. When creating a solution, the engineer must keep in mind that the tool must support these requirements:
1.
Allow the rapid creation and removal of logical containers.
2.
Support the creation of custom modules and data structures.
3.
Be extensible with external libraries and modules.
4.
Allow rapid testing of code using an on-demand execution environment. Which automation tool meets these requirements?
A. SaltStack
B. YAML
C. Chef
D. Python
An engineer must create an EPG called "Test". The configuration request should succeed if the Tenant called "Tenant" and the application profile called "Test" exist. The firewall policy allows only the HTTP connectivity to APIC from the user's computer.
Which action accomplishes this goal?
A. Send
B. Send
C. Send
D. Send
A network engineer is configuring the Cisco UCS service profile template with Ansible using this code:
hostname: 192.168.10.23 username: cisco password: f718c4329405726531f6247ff982 name: DCE-CTRL template_type: updating-template uuid_pool: UUID-POOL storage_pronte: DCE-StgProf maintenance_policy: default server_pool: Container-Pool host_firmware_package: 4.1(1a) bios_policy: Docker
Which attribute must be used to apply the iSCSI initiator identifiers to all iSCSI vNICs for the service profiles derived from the service template?
A. san_connectivity_policy
B. lan_connectivity_policy
C. boot_policy
D. iqn_pool
An engineer must implement private VLANs for a group of Cisco UCS 8-Series servers. The primary VLAN is present, But the secondary VLAN must Be added to Both fabrics.
Which configuration set accomplishes this task?
A. UCS-A# scope eth-uplink UCS-A /eth-uplink # create vlan vlan1981 1981 UCS-A /eth-uplink/vlan* # set sharing none
B. UCS-A# scope eth-uplink UCS-A /eth-uplink # create vlan vlan1981 1981 UCS-A /eth-uplink/vlan* # set sharing isolated
C. UCS-A# scope eth-uplink UCS-A /eth-uplink # scope fabric a UCS-A /eth-uplink/fabric # create vlan vlan1981 1981 UCS-A /eth-uplink/fabric/vlan* # set sharing secondary
D. UCS-A# scope eth-uplink UCS-A /eth-uplink # scope fabric a UCS-A /eth-uplink/fabric # create vlan vlan1981 1981 UCS-A /eth-uplink/fabric/vlan* # set sharing private
Refer to the exhibit.
An engineer configures port security on a Cisco Nexus 9000 Series Switch. The requirement is to prevent any newly learned MAC addresses from forwarding traffic on the interface. Also, the already learned MAC addresses must not be affected by the changes.
Which configuration meets these requirements?
A. switchport port-security violation shutdown
B. switchport port-security violation isolate
C. switchport port-security violation protect
D. switchport port-security violation restrict
What is a characteristic of EPLD updates on Cisco MDS 9000 Series Switches?
A. EPLD updates are installed only via the Cisco DCNM GUI
B. EPLD packages update hardware functionality on a device
C. EPLD bundles are released separately from a Cisco MDS NX-OS release
D. EPLD updates are nondisruptive to traffic flow
A Cisco MDS 9000 Series Switch is configured for SAN Analytics and SAN Telemetry Streaming. An engineer must enable analytics for NVMe on interfaces in the range of fc1/1-12. Due to a large amount of traffic generated in the SAN environment, the data must be collected at regular intervals of 60 seconds from ports fc1/1-12 and then for ports fc1/13-24 for the next 60 seconds. Ports in the range fc1/13-24 were already enabled for analytics.
Which set of commands must be used to meet these requirements?
A. Option A
B. Option B
C. Option C
D. Option D
